Stainless Steel Flexible Hose with EPDM Inner Tube Double Lock and Customizable Size

MOQ:	500
Price:	1.15

Details Information

Product Description

Detail Information

Head Type:

Hexagon

Pipe Diameter:

DN1/2-32inch (DN12-800mm)

Pipe Material:

SS321, 304, 316, 316L

Pipe Type:

Annular Corrugated Pipe

Pipe Thickness:

0.28-1.0mm

Braided Mesh Material:

SS304

Braided Mesh Layer:

Single Layer Or Double Layers Or Three Layer

Max Working Pressure:

10Mpa~35MPa

Working Temperature:

(-200)~(+800) °c

Connect Type:

Flange, Nuts, Fast Fittings

Flange Material:

Stainless Steel Or Carbon Steel

Pipe Assembly Length:

According To Clients' Requirements

Steel Thickness:

0.12-0.2mm

Transport Package:

Carton Box

HS Code:

8307100000

Highlight:

EPDM Inner Tube Flexible Hose

Double Lock Metal Hose

Customizable Size Stainless Steel Hose

Product Description

Flexible Hose Stainless Steel EPDM Inner Tube Double Lock Shower Toilet Flexible Hose

We manufacture custom flexible hoses and metal bellows according to customer specifications for both length and nominal diameter. Our products feature soft, elastic, and lightweight construction using 0.12-0.2mm thickness steel plates.

Product Specifications

Parameter	Specification
Pipe Diameter	DN1/2-32inch (DN12-800mm)
Pipe Material	SS321, 304, 316, 316L
Pipe Type	Annular corrugated pipe
Pipe Thickness	0.28-1.0mm
Braided Mesh Material	SS304
Braided Mesh Layer	Single, double, or three layers
Maximum Working Pressure	10Mpa~35MPa
Working Temperature	(-200)~(+800) °C
Connection Type	Flange, nuts, fast fittings
Standards	GB/T14525-2010, ANSI, JIS, DIN, GOST
Flange Material	Stainless steel or carbon steel
Pipe Assembly Length	Customized per client requirements

Main Products

Stainless steel flexible metal hose
Expansion joints
Bellows and convoluted tubes
Stainless steel braided nets

Customization Requirements

For customized orders, please provide the following parameters:

Material specifications (SS304, 321, 316, 316L, etc.)
End connection types (flange, screw nuts, fast fittings, etc.)
Outer and inner diameter measurements
Length and pressure requirements
Application details

We appreciate receiving drawings, blueprints, or pictures for reference. Please contact us with any questions or requirements.

Production Process

Steel plate rolling and cutting to specified width
Rolling and automatic welding of steel pipes
Bellows forming using hydraulic systems and molds
Steel wire braided reinforcement assembly
Welding of nuts, joints, and hose components
Pressure testing to ensure 100% leak-free performance

Company Introduction

Wuxi City Ge Ming Sheng Steel Trading Co., Ltd (China Metal Hose Factory) is located in China's Wuxi Rubber and Plastic Pipe Base. Founded in 2012 with 50 employees, including 100 professional and senior technicians, we specialize in manufacturing stainless steel metal hoses, metal bellows, nets, metal and non-metallic compensators, polyurethane products, high/low pressure hoses, hose sheathed insulation, and various connectors.

Our products are widely used in electric power, dock construction, steel, mining, petroleum, chemical, cement, transportation, and other industrial applications. All products have passed ISO9001 international quality system certification.
