ISO ASTM A276 Grade 304 Hot Rolled Stainless Steel Angle Bar 6m Length

MOQ:	30
Price:	1.72

Details Information

Product Description

Detail Information

Shape:

U Channel

Technique:

Hot Rolled

Surface Treatment:

Bright

Specification:

30*30-100*100

Grade:

201 304 310S 316L 321 2205

Standard:

ASTM GB DIN

Angle Bar Size:

30*30*3 - 200*200*10mm

Channel Bar Size:

50*30*3 - 200*100*10mm

Length:

Angle Bar Weight:

0.894 - 15.0 Kg/m

Channel Bar Weight:

1.79 - 35.8 Kg/m

Thickness Range:

3 - 12mm

Material:

Stainless Steel

Service:

Cutting

Packing:

Waterproof Paper Or Wooden Pallets

Highlight:

ISO ASTM A276 Grade 304 Stainless Steel Angle Bar

Hot Rolled SS Angle Bar

6m Length Stainless Steel Channel Bar

Product Description

ISO ASTM A276 Grade 304 Stainless Steel Angle Bar - 6m Length

High-quality stainless steel angle and channel bars manufactured to international standards for industrial and construction applications.

Product Specifications

Product Name: Stainless Steel Angle Bar / Stainless Steel Channel Bar

Grade: 201, 304, 310S, 316L, 321, 2205, etc.

Standard: ASTM, GB, DIN

Angle Bar Size: 30×30×3 - 200×200×10mm × 6m length

Channel Bar Size: 50×30×3 - 200×100×10mm × 6m length

Service: Cutting

Packing: Waterproof paper surround or wooden pallets

Brand: TSINGSHAN

Stainless Steel Angle Bar - Standard Sizes & Weight per Meter

Size A×B (mm)	3mm	4mm	5mm	6mm	7mm	8mm	9mm	10mm
20×20	0.894	1.13	1.38
25×25	1.13	1.45	1.77	2.06
30×30	1.37	1.77	2.17	2.53
35×35	1.61	2.09	2.57	3.01
40×40	1.85	2.41	2.97	3.49
45×45	2.12	2.76	3.40	4.00
50×50	2.36	3.07	3.79	4.46	5.13	5.76	6.42	7.06
60×60			4.58	5.42	6.24	7.03
63×63			5.03	5.95	6.84	7.71	8.60	9.48
70×70			5.42	6.42	7.39	8.34	9.31	10.3
75×75			5.82	6.89	7.95	8.97	10.0	11.1
80×80				7.37	8.50	9.61	10.7	11.8
90×90				8.33	9.65	11.90	12.2	13.4
100×100				9.28	10.8	12.20	13.6	15.0

Stainless Steel Channel Bar - Standard Sizes & Weight per Meter

Size H×B (mm)	3mm	4mm	5mm	6mm	7mm	8mm	9mm	10mm	12mm
40×20	1.79
50×25	2.27
60×30	2.74	3.56	4.37	5.12
70×35	3.23	4.21	5.17	6.08
80×40	3.71	4.84	5.96	7.03
90×45	4.25	5.55	6.83	8.05
100×50	4.73	6.18	7.62	8.98	10.3	11.7	13.0	41.2
120×60			9.20	10.9	12.6	14.2
130×65			10.1	11.9	13.8	15.5	17.3	19.1
140×70				12.9	14.9	16.8	18.8	20.7
150×75				13.9	16.0	18.1	20.2	22.2	26.3
160×80				14.8	17.1	19.3	21.6	23.8	28.1
180×90				16.7	19.4	22.0	24.5	27.0	32.0
200×100				18.6	21.6	24.5	27.4	30.2	35.8

About Our Company

Our company is a comprehensive stainless steel enterprise specializing in material wholesale, processing, storage, and distribution. Located in Wuxi, the stainless steel trading center, we have a total investment of 10 million yuan with annual sales exceeding 300 million yuan.

Strategic Partnerships

We maintain long-term, stable cooperative relationships with renowned steel mills including Taiyuan, East, Zhang Pu, Hongxing, Zhejiang Qingshan, and distribute imported stainless steel plates from Sweden, North America, South Africa, Japan, and South Korea.

Material Range

Our product portfolio includes 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205-904L and other materials covering high-temperature resistant stainless steel series, duplex stainless steel series, and super stainless steel series.

Processing Capabilities

Plasma cutting machines
Coil material opening equipment
Laser cutting machines
8K mirror, grinding wire drawing, film and titanium plating equipment
Material opening, strip, plate cutting, oil mill wire drawing
Whole coil oil film wire drawing, 8K mirror, titanium processing

Specialized Services

We specialize in thick plate whole plate zero cutting, cutting round, cutting square, cutting shaped parts, casting parts, forging parts with product thickness up to 150MM. All special materials and specifications can be customized to steel mill requirements according to customer specifications.

Industry Applications: Machinery, chemical, petroleum, boiler, heat exchanger, food machinery, beverage machinery, medical equipment and other industries.

Product Gallery

Applications

Stainless steel angle bars and channel bars are primarily used for constructing frame structures including:

High-voltage power transmission towers
Frame structures on both sides of main beams in steel bridge construction
Column and boom components of tower cranes on construction sites
Column and beam structures in workshop construction
Air-conditioning and solar-powered shelf supports under windows

Widely utilized in building structures and engineering projects such as house beams, ship beams, industrial furnaces, and various construction applications across multiple industries.

Contact Information

For inquiries about our stainless steel angle bars, channel bars, or custom processing services, please contact our sales team for detailed specifications and pricing.
