| MOQ: | 500kg |
| 가격: | 2.15-4.65 USD/KG |
| 표준 포장: | 수출 포장 |
| 배달 기간: | 7일 |
| 지불 방법: | L/C, T/T, 웨스턴 유니온 |
| 공급 능력: | 500톤 |
| Grade | S32101 S32304 S32205 S32750 S32760 . |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB,ASME,ETC |
| Width | 1000,1219,1250,1500mm,1800mm,2000mm,or as your requirements |
| Length | 2000mm, 2438mm,2500mm,3000mm,6000mm,or as your requirements |
| Thickness | 0.5mm-150mm |
| Surface | No.1,2B,BA,8K,Mirror,Hairline,Satin,Embossed,Brush,No.4,HL,matt,PVC,Film,Laser film |
| Brand | TISCO,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS BV IQI,TUV,ISO,ETC |
Stainless steel grade Duplex 2101 LDX is a low-alloyed, general-purpose duplex. This steel possesses high tensile strength as well as high fatigue strength. Its high mechanical strength is same as other duplex grades, and its good corrosion resistance is equal to most standard stainless steel grades. All these properties are utilized to design products with strength, low maintenance, durability and long-term cost efficiency.
The following datasheet provides an overview of stainless steel grade Duplex 2101 LDX.
The chemical composition of stainless steel grade Duplex 2101 LDX is outlined in the following table.
| Element | Content (%) |
|---|---|
| Iron, Fe | 71.45 |
| Chromium, Cr | 21.5 |
| Manganese, Mn | 5 |
| Nickel, Ni | 1.5 |
| Molybdenum, Mo | 0.3 |
| Nitrogen, N | 0.220 |
| Carbon, C | 0.03 |
The mechanical properties of stainless steel grade Duplex 2101 LDX are displayed in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength (annealed) | 696 MPa | 101000 psi |
| Yield strength (@strain 0.200 %) | 450 MPa | 65300 psi |
| Modulus of elasticity | 200 GPa | 29000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poisson’s ratio | 0.3 | 0.3 |
| Elongation at break (In 2", 50% cold worked) | 38% | 38% |
The applications of stainless steel grade Duplex 2101 LDX are as follows:
AQ
Q: Are you a manufacturer or merely a trader?
A: We are group of companies and owned manufacturer bases and trading company. We specialized in special steel which include alloy structural steel and carbon steel and stainless steel, etc. All material are with high quality and competitive price.
Q: How do you guarantee the quality of your product?
A: Firstly, we can provide the certificates from the third party, such as TUV, CE, if you need. Secondly, we have a complete set of inspection system and every process is checked by QC. Quality is the lifeline of enterprise survival.
Q: Delivery time?
A: We have ready stock for most of material grades in our warehouse. If the material don't have stock, the delivery lead time is about 5-30 days after receiving your prepayment or firm order.
Q: What is the payment term?
A: T/T or L/C.
Q: Can you provide a sample for our testing before confirm the order?
A: Yes. We can provide sample to you for approval before you place an order to us. Free sample is available if we have stock.
Q: Can we visit your company and factory?
A: Yes, warmly welcome! We can book the hotel for you before you come to China and arrange our driver to our airport to pick you up.
|
|
